6313-C
Deep groove ball bearing
Deep groove ball bearing 63..-C, single row, Generation C, steel sheet metal cage
Prodotto preferito
Informazione sul prodotto
Main Dimensions & Performance Data
| d | 65 mm | Bore diameter |
| D | 140 mm | Outside diameter |
| B | 33 mm | Width |
| Cr | 101.000 N | Basic dynamic load rating, radial |
| C0r | 60.000 N | Basic static load rating, radial |
| Cur | 4.100 N | Fatigue load limit, radial |
| nG | 7.300 1/min | Limiting speed |
| nϑr | 7.000 1/min | Reference speed |
| ≈m | 2,008 kg | Peso |
Mounting dimensions
| da min | 77 mm | Minimum diameter shaft shoulder |
| Da max | 128 mm | Maximum diameter of housing shoulder |
| ra max | 2,1 mm | Maximum fillet radius |
Dimensions
| rmin | 2,1 mm | Minimum chamfer dimension |
| D1 | 118,22 mm | Shoulder diameter outer ring |
| D2 | 121,4 mm | Caliber diameter outer ring |
| d1 | 87,73 mm | Shoulder diameter inner ring |
| d2 | 85,59 mm | Caliber diameter inner ring |
Temperature range
| Tmin | -30 °C | Operating temperature min. |
| Tmax | 150 °C | Operating temperature max. |
Calculation factors
| f0 | 13,2 | Calculation factor |
